LICENSE PLATE LIGHT SHORT-CORD INSPECTION

1. Disconnect the negative battery cable. (See NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION.)
2. Remove the trunk end trim. (See TRUNK END TRIM REMOVAL/INSTALLATION.)
3. Partially peel back the trunk side trim. (See TRUNK SIDE TRIM REMOVAL/INSTALLATION.)
4. Remove the following parts:
a. Rear combination light (See REAR COMBINATION LIGHT REMOVAL/INSTALLATION.)
b. Rear splash shield (See REAR SPLASH SHIELD REMOVAL/INSTALLATION.)
c. Rear bumper stay (See REAR BUMPER STAY REMOVAL/INSTALLATION.)
d. Rear bumper retainer No.1 (See REAR BUMPER RETAINER No.1 REMOVAL/INSTALLATION.)
e. Rear bumper (See REAR BUMPER REMOVAL.) (See REAR BUMPER INSTALLATION.)
f. License plate light short-cord (See LICENSE PLATE LIGHT SHORT-CORD REMOVAL/INSTALLATION.)
5. Verify that the continuity between the license plate light short-cord terminals is as indicated in the table.
